Weld Inspection

Ultrasonic testing involves emitting high pitched waves into the welded section of rail in order to detect internal flaws.

Ultrasonic Weld Testing product overview

This comprehensive test is carried out on the head, web and foot to provide a detailed analysis of the entire weld.

  • This allows the user to determine whether or not the weld has confirmed to the specifications of the rail network

Downloads

Catalogue

Benefits of the Ultrasonic Weld Testing

01

Prevents breakage

Prevents breaking in the weld

02

Precise

The outputted report will highlight the exact location, characteristics and cause of the defect inside the weld

Technical features of the Ultrasonic Weld Testing

01

Inspects 100% of the weld

Multiple angles are used to inspect 100% of the weld

02

Detects infects

Detects a variety of defects including blowholes, insufficient fusion and shrinkage
